How to identify computer ram ddr1 ddr2 ddr3, DDR4 Identifying the Computer RAM (Random Access Memory) like DDR1, DDR2, DDR3, and DDR4 physically is not so hard if you follow the steps.

1. Distance of Notch
2. Integrated Chip (IC) type

Ram Slot Expander Ddr3 Adapter

DDR1, DDR2, DDR3, DDR4 is the most using RAM currently in the market.

• DDR3L is a dual voltage capable memory DIMM, which supports operation at both 1.5V and 1.35V. DDR3L is also pin-compatible with DDR3! DDR3 is a single voltage capable memory DIMM, which supports 1.5V operation only. So, in this case the RAM will be running at 1.5 volts as your system does not offer a low voltage option.
• When upgrading the RAM in a user's computer a technician installs memory that is DDR3 1066 MHz in one RAM slot and DDR3 1333 MHz in the other. On which of the following bus speeds will the system function? 1066, RAM will function at the slower of the 2 speeds.

Ram Slot Expander Ddr3 Vs

First of all confirm is it DDR1, DDR2, DDR3, or Different DDR’s SDRAM. keep your DDR chip front-facing as given bellow. here look to the notch each DDR notch distance is different from others DDR. It’s mentioned in the picture.

TEAMGROUP Elite DDR3 16GB Kit (2 x 8GB) 1600MHz (PC3-12800) CL11 Unbuffered Non-ECC 1.5V UDIMM 240 Pin PC Computer Desktop Memory Module Ram Upgrade - TED316G1600C11DC01-16GB Kit (2 x 8GB) 4.7 out of 5 stars 1,026.

Also Read :

Distance of Notch

• • Notch Means above cuts Mark on RAM
    • DDR1, DDR2, DDR3 having Single Cut mark on the base of the RAM
  • But you can see the Cut mark (Notch) distance (see below photo)
    • Notch of DDR1 and DDR2 are similar but if you see closely,
      • You can find DDR1 Notch is just above the IC and DDR
      • DDR2 Notch is just far to the IC
    • Notch of DDR3 is different from the other two.

• Integrated Chip (IC)

  • See the Above Photo
    • DDR3 having small and square type IC.
    • DDR2 is just bigger then DDR3 and smaller the DDR1,
    • In this case, too, DDR1 and DDR2 are just a small difference
      • IC in DDR1 are touched both top and bottom of RAM
      • and IC in DDR2 is just center of the RAM

• Number of Pins in DDR1, DDR2, DDR3, DDR4

  • DDR1 – 184 Pins
    • DDR2 – 240 Pins
      • DDR3 – 240 Pins
        • DDR4 – 288 Pins

• Voltage of RAM

  • The voltage of RAM cannot be used for the Physical finding of RAM, but it can be used to place the RAM in the Motherboard Slot. (voltage are written in the RAM Slot of Motherboard)
    • DDR1 Volts – 2.5 v
      • DDR 2 Volts – 1.8 v
        • DDR3 Volts – 1.5 v
          • DDR4 Volts – 1.2v
